4.1 Visualize Fractions

The topics covered in this section are:

1. Understand the meaning of fractions
2. Model improper fractions and mixed numbers
3. Convert between improper fractions and mixed numbers
4. Model equivalent fractions
5. Find equivalent fractions
6. Locate fractions and mixed numbers on the number line
7. Order fractions and mixed numbers

4.1.1 Understand the Meaning of Fractions

Andy and Bobby love pizza. On Monday night, they share a pizza equally. How much of the pizza does each one get? Are you thinking that each boy gets half of the pizza? That’s right. There is one whole pizza, evenly divided into two parts, so each boy gets one of the two equal parts.

In math, we write $\frac{1}{2}$ to mean one out of two parts.

On Tuesday, Andy and Bobby share a pizza with their parents, Fred and Christy, with each person getting an equal amount of the whole pizza. How much of the pizza does each person get? There is one whole pizza, divided evenly into four equal parts. Each person has one of the four equal parts, so each has $\frac{1}{4}$ of the pizza.

On Wednesday, the family invites some friends over for a pizza dinner. There are a total of $12$ people. If they share the pizza equally, each person would get $\frac{1}{12}$ of the pizza.

Fractions

A fraction is written $\frac{a}{b}$, where $a$ and $b$ are integers and $b \neq 0$. In a fraction, $a$ is called the numerator and $b$ is called the denominator.

A fraction is a way to represent parts of a whole. The denominator $b$ represents the number of equal parts the whole has been divided into, and the numerator 𝑎a represents how many parts are included. The denominator $b$,cannot equal zero because division by zero is undefined.

In the figure below, the circle has been divided into three parts of equal size. Each part represents $\frac{1}{3}$ of the circle. This type of model is called a fraction circle. Other shapes, such as rectangles, can also be used to model fractions.

What does the fraction $\frac{2}{3}$ represent? The fraction $\frac{2}{3}$ means two of three equal parts.

Example 1

Name the fraction of the shape that is shaded in each of the figures.

Example 2

Shade $\frac{3}{4}$ of the circle.

In Example 1 and Example 2, we used circles and rectangles to model fractions. Fractions can also be modeled as manipulatives called fraction tiles, as shown in the figure below. Here, the whole is modeled as one long, undivided rectangular tile. Beneath it are tiles of equal length divided into different numbers of equally sized parts.

We’ll be using fraction tiles to discover some basic facts about fractions. Refer to the above figure to answer the following questions:

How many $\frac{1}{2}$ tiles does it take to make one whole tile?	It takes two halves to make a whole, so two out of two is $\frac{2}{2} = 1$.
How many $\frac{1}{3}$ tiles does it take to make one whole tile?	It takes three thirds, so three out of three is $\frac{3}{3} = 1$.
How many $\frac{1}{4}$ tiles does it take to make one whole tile?	It takes four fourths, so four out of four is $\frac{4}{4} = 1$.
How many $\frac{1}{6}$ tiles does it take to make one whole tile?	It takes six sixths, so six out of six is $\frac{6}{6} = 1$.
What if the whole were divided into $24$ equal parts? (We have not shown fraction tiles to represent this, but try to visualize it in your mind.) How many $\frac{1}{24}$ tiles does it take to make one whole tile?	It takes $24$ twenty-fourths, so $\frac{24}{24} = 1$.

It takes $24$ twenty-fourths, so $\frac{24}{24} = 1$.

This leads us to the Property of One.

PROPERTY OF ONE

Any number, except zero, divided by itself is one.

$\frac{a}{a} =1$ where $(a \neq 0)$

Example 3

Use fraction circles to make wholes using the following pieces:

1. $4$ fourths
2. $5$ fifths
3. $6$ sixths

What if we have more fraction pieces than we need for $1$ whole? We’ll look at this in the next example.

Example 4

Use fraction circles to make wholes using the following pieces:

1. $3$ halves
2. $8$ fifths
3. $7$ thirds

4.1.2 Model Improper Fractions and Mixed Numbers

In Example 4 (Part 2.) you had eight equal fifth pieces. You used five of them to make one whole, and you had three fifths left over. Let us use fraction notation to show what happened. You had eight pieces, each of them one fifth, $\frac{1}{5}$, so altogether you had eight fifths, which we can write as $\frac{8}{5}$. The fraction $\frac{8}{5}$ is one whole, $1$, plus three fifths, $\frac{3}{5}$, or $1 \frac{3}{5}$, which is read as one and three-fifths.

The number $1 \frac{3}{5}$ is called a mixed number. A mixed number consists of a whole number and a fraction.

MIXED NUMBERS

A mixed number consists of a whole number $a$ and a fraction $\frac{a}{b}$ where $c \neq 0$. It is written as follows.

$a \frac{b}{c}$ where $c \neq 0$.

Fractions such as $\frac{5}{4}, \frac{3}{2}, \frac{5}{5}$, and $\frac{7}{3}$ are called improper fractions. In an improper fraction, the numerator is greater than or equal to the denominator, so its value is greater than or equal to one. When a fraction has a numerator that is smaller than the denominator, it is called a proper fraction, and its value is less than one. Fractions such as $\frac{1}{2}, \frac{3}{7}$, and $\frac{11}{18}$ are proper fractions.

PROPER AND IMPROPER FRACTIONS

The fraction $\frac{a}{b}$ is a proper fraction if $a<b$ and an improper fraction if $a \geq b$.

Example 5

Name the improper fraction modeled. Then write the improper fraction as a mixed number.

Example 6

Draw a figure to model $\frac{11}{8}$.

Example 7

Use a model to rewrite the improper fraction $\frac{11}{6}$ as a mixed number.

Example 8

Use a model to rewrite the mixed number $1 \frac{4}{5}$ as an improper fraction.

4.1.3 Convert between Improper Fractions and Mixed Numbers

In Example 7, we converted the improper fraction $\frac{11}{6}$ to the mixed number $1 \frac{5}{6}$ using fraction circles. We did this by grouping six sixths together to make a whole; then we looked to see how many of the $11$ pieces were left. We saw that $\frac{11}{6}$ made one whole group of six sixths plus five more sixths, showing that $\frac{11}{6} = 1 \frac{5}{6}$.

The division expression $\frac{11}{6}$ (which cam also be written as 6)11) tells us to find how many groups of $6$ are in $11$. To convert an improper fraction to a mixed number without fraction circles, we divide.

Example 9

Convert $\frac{11}{6}$ to a mixed number.

HOW TO: Convert an improper fraction to a mixed number.

1. Divide the denominator into the numerator.
2. Identify the quotient, remainder, and divisor.
3. Write the mixed number as quotient $\frac{remainder}{divisor}$.

Example 10

Convert the improper fraction $\frac{33}{8}$ to a mixed number.

In Example 8, we changed $1 \frac{4}{5}$ to an improper fraction by first seeing that the whole is a set of five fifths. So we had five fifths and four more fifths.

$\frac{5}{4} + \frac{4}{5} = \frac{9}{5}$

Where did the nine come from? There are nine fifths—one whole (five fifths) plus four fifths. Let us use this idea to see how to convert a mixed number to an improper fraction.

Example 11

Convert the mixed number $4 \frac{2}{3}$ to an improper fraction.

HOW TO: Convert a mixed number to an improper fraction.

1. Multiply the whole number by the denominator.
2. Add the numerator to the product found in Step 1.
3. Write the final sum over the original denominator.

Example 12

Convert the mixed number $10 \frac{2}{7}$ to an improper fraction.

4.1.4 Model Equivalent Fractions

Let’s think about Andy and Bobby and their favorite food again. If Andy eats $\frac{1}{2}$ of a pizza and Bobby eats $\frac{2}{4}$ of the pizza, have they eaten the same amount of pizza? In other words, does $\frac{1}{2} = \frac{2}{4}$? We can use fraction tiles to find out whether Andy and Bobby have eaten equivalent parts of the pizza.

EQUIVALENT FRACTIONS

Equivalent fractions are fractions that have the same value.

Fraction tiles serve as a useful model of equivalent fractions. You may want to use fraction tiles to do the following activity. Or you might make a copy of the figure near the top of the webpage and extend it to include eights, tehnths, and twelfths.

Start with a $\frac{1}{2}$ tile. How many fourths equal one-half? How many of the $\frac{1}{4}$ tiles exactly cover the $\frac{1}{2}$ tile?

Since two $\frac{1}{4}$ tiles cover the $\frac{1}{2}$ tile, we see that $\frac{2}{4}$ is the same as $\frac{1}{2}$, or $\frac{2}{4} = \frac{1}{2}$.

How many of the $\frac{1}{6}$ tiles cover the $\frac{1}{2}$ tile?

Since three $\frac{1}{6}$ tiles cover the $\frac{1}{2}$ tile, we see that $\frac{3}{6}$ is the same as $\frac{1}{2}$.

So. $\frac{3}{6} = \frac{1}{2}$. The fractions are equivalent fractions.

Example 13

Use fraction tiles to find equivalent fractions. Show your result with a figure.

1. How many eighths equal one-half?
2. How many tenths equal one-half?
3. How many twelfths equal one-half?

4.1.5 Find Equivalent Fractions

We use fraction tiles to show that there are many fractions equivalent to $\frac{1}{2}$. For example, $\frac{2}{4}, \frac{3}{6}$, and $\frac{4}{8}$ are all equivalent to $\frac{1}{2}$. When we lined up the fraction tiles, it took four of the $\frac{1}{8}$ tiles to make the same length as a $\frac{1}{2}$ tile. This showed that $\frac{4}{8} = \frac{1}{2}$. See Example 13.

We can show this with pizzas, too. The figure(a) below shows a single pizza, cut into two equal pieces with $\frac{1}{2}$ shaded. The figure(b) below shows a second pizza of the same size, cut into eight pieces with $\frac{4}{8}$ shaded.

This is another way to show that $\frac{1}{2}$ is equivalent to $\frac{4}{8}$.

How can we use mathematics to change $\frac{1}{2}$ into $\frac{4}{8}$? How could you take a pizza that is cut into two pieces and cut it into eight pieces? You could cut each of the two larger pieces into four smaller pieces! The whole pizza would then be cut into eight pieces instead of just two. Mathematically, what we’ve described could be written as:

These models lead to the Equivalent Fractions Property, which states that if we multiply the numerator and denominator of a fraction by the same number, the value of the fraction does not change.

EQUIVALENT FRACTIONS PROPERTY

If $a,b$, and $c$ are numbers where $b \neq 0$ and $c \neq 0$, then

$\frac{a}{b} = \frac{a \cdot c}{b \cdot c}$

When working with fractions, it is often necessary to express the same fraction in different forms. To find equivalent forms of a fraction, we can use the Equivalent Fractions Property. For example, consider the fraction one-half.

So, we say that $\frac{1}{2}, \frac{2}{4}, \frac{3}{6}$, and $\frac{10}{20}$ are equivalent fractions.

Example 14

Find three fractions equivalent to $\frac{2}{5}$.

Example 15

Find a fraction with a denominator of $21$ that is equivalent to $\frac{2}{7}$.

4.1.6 Locate Fractions and Mixed Numbers on the Number Line

Now we are ready to plot fractions on a number line. This will help us visualize fractions and understand their values.

Let us locate $\frac{1}{5}, \frac{4}{5}, 3, 3 \frac{1}{3}, \frac{7}{4}, \frac{9}{2}, 5$, and $\frac{8}{3}$ on the numberline.

We will start with the whole numbers $3$ and $5$ because they are the easiest to plot.

The proper fractions listed are $\frac{1}{5}$ and $\frac{4}{5}$. We know proper fractions have values less than one, so $\frac{1}{5}$ and $\frac{4}{5}$ are located between the whole numbers $0$ and $1$. The denominators are both $5$, so we need to divide the segment of the number line between $0$ and $1$ into five equal parts. We can do this by drawing four equally spaced marks on the number line, which we can then label as $\frac{1}{5}, \frac{2}{5}, \frac{3}{5}$, and $\frac{4}{5}$.

Now plot points at $\frac{1}{5}$ and $\frac{4}{5}$.

The only mixed number to plot is $3 \frac{1}{3}$. Between what two whole numbers is $3 \frac{1}{3}$? Remember that a mixed number is a whole number plus a proper fraction, so $3 \frac{1}{3} > 3$. Since it is greater than $3$, but not a whole unit greater, $3 \frac{1}{3}$ is between $3$ and $4$. We need to divide the portion of the number line between $3$ and $4$ into three equal pieces (thirds) and plot $3 \frac{1}{3}$ at the first mark.

Finally, look at the improper fractions $\frac{7}{4}, \frac{9}{2}$, and $\frac{8}{3}$. Locating these points will be easier if you change each of them to a mixed number.

$\frac{7}{4} = 1 \frac{3}{4}, \frac{9}{2} = 4 \frac{1}{2}, \frac{8}{3} = 2 \frac{2}{3}$

Here is the number line with all points plotted.

Example 16

Locate and label the following on a number line: $\frac{3}{4}, \frac{4}{3}, \frac{5}{3}, 4 \frac{1}{5}$, and $\frac{7}{2}$.

In Introduction to Integers, we defined the opposite of a number. It is the number that is the same distance from zero on the number line but on the opposite side of zero. We saw, for example, that the opposite of $7$ is $-7$ and the opposite of $-7$ is $7$.

Fractions have opposites, too. The opposite of $\frac{3}{4}$ is $\frac{-3}{4}$. It is the same distance from $0$ on the number line, but on the opposite side of $0$.

Thinking of negative fractions as the opposite of positive fractions will help us locate them on the number line. To locate $\frac{-15}{8}$ on the number line, first think of where $\frac{15}{8}$ is located. It is an improper fraction, so we first convert it to the mixed number $1 \frac{7}{8}$ and see that it will be between $1$ and $2$ on the number line. So its opposite, $\frac{-15}{8}$, will be between $-1$ and $-2$ on the number line.

Example 17

Locate and label the following on the number line: $\frac{1}{4}, – \frac{1}{4}, 1 \frac{1}{3}, -1 \frac{1}{3}, \frac{5}{2}$, and $- \frac{5}{2}$.

4.1.7 Order Fractions and Mixed Numbers

We can use the inequality symbols to order fractions. Remember that $a>b$ means that $a$ is to the right of $b$ on the number line. As we move from left to right on a number line, the values increase.

Example 18

Order each of the following pairs of numbers, using $<$ or $>$:

1. $- \frac{2}{3}$ ____ $-1$
2. $-3 \frac{1}{2}$ ____ $-3$
3. $- \frac{3}{7}$ ____ $- \frac{3}{8}$
4. $-2$ ____ $\frac{-16}{9}$
